Application

Granules , Namkeen, Tea, Coffee, Powder, Dryfruits , Seeds, Chips, Fryums, Frozen Vegetables and Fruits, Small Solid Materials.


Specifications

  • Capacity :-50gm to 1000gm (Different Types Of Machines.)
  • Pouch Type – Pillow Type ,Center Sealing Machine
  • Film Size :- 150-450mmW , 100-300mm L
  • Speed :- 20-50 pouch per min. Weight Accuarty - [+/-3gm]
  • Power :-3KW, 420V,3-Phase
  • Net Weight :-650kg to 700kg.(Approx)
  • Dimension :- 12690 x 1200 x 2835 (LxWxH)
  • Compressor Required :-5CFM@5BAR.
  • Packing Material- All Heat Sealable Laminates Max Roll Width -380mm

Features

  • Complete Machine Construction is of M.S & All Product Contact Parts are of S/S 304.
  • Machine is controlled through PLC-Programmed Logic Controller
  • Alert Indication for end of Film Roll.
