Application
Granules , Namkeen, Tea, Coffee, Powder, Dryfruits , Seeds, Chips, Fryums, Frozen Vegetables and Fruits, Small Solid Materials.
Specifications
- Capacity :-50gm to 1000gm (Different Types Of Machines.)
- Pouch Type – Pillow Type ,Center Sealing Machine
- Film Size :- 150-450mmW , 100-300mm L
- Speed :- 20-50 pouch per min. Weight Accuarty - [+/-3gm]
- Power :-3KW, 420V,3-Phase
- Net Weight :-650kg to 700kg.(Approx)
- Dimension :- 12690 x 1200 x 2835 (LxWxH)
- Compressor Required :-5CFM@5BAR.
- Packing Material- All Heat Sealable Laminates Max Roll Width -380mm
Features
- Complete Machine Construction is of M.S & All Product Contact Parts are of S/S 304.
- Machine is controlled through PLC-Programmed Logic Controller
- Alert Indication for end of Film Roll.
